10 Parameter List PumpDrive 2
143 of
212
Parameter Description Help text Possible settings Unit Factory setting
3-3-4-1 Update Motor
Parameters
Function used to start automatic motor
adaptation (AMA) for the KSB SuPremE
motor.
Using the nominal motor data as a basis,
the extended motor data is determined
which ensures very good control of the KSB
SuPremE motor.
Run
3-3-4-2 Selected Motor KSB SuPremE motor variant currently
selected
Motor-specific
3-3-4-3 Efficiency Optimisation Efficiency optimisation ON / OFF ON
3-3-5 Ramps
3-3-5-1 Start Ramp Time Time defining the start ramp 0,0 … 600,0 s 3,0
3-3-5-2 Stop Ramp Time Time defining the stop ramp 0,0 … 600,0 s 3,0
3-3-5-3 Operating Ramp Time Time defining the ramps for speed changes
in open-loop control mode or in manual
mode
0,0 … 600,0 s 3,0
3-3-6 PWM
3-3-6-1 Switching Frequency Configurable switching frequency of power
inverter in the frequency inverter power
output stage
2 … 8 kHz Dependent on
size
3-3-6-2 Random PWM ▪ OFF
▪ ON
OFF
3-3-7 Additional Frequency
Inverter Settings
3-3-7-1 Max. Motor Current in
% of Nominal Motor
Current
Configuring the maximum motor current
permissible
0,00 ...150,00 % 110
3-3-7-5 I²t Triggering
Characteristic
Based on the I²t triggering characteristic, a
period of time is calculated dynamically
during which the motor may be operated at
a higher current until I²t control is activated.
1 … 60 s 60
3-3-7-6 I²t Stop Speed This speed limit causes a Dynamic Overload
Protection alert to be output, at which time
the motor is stopped.
3-2-2-1 … 3-2-2-2 rpm 3-2-2-1
3-3-8 MotionControl
Controller Settings
3-3-8-1 Proportional
Constant_Current (KpI)
Setting the proportional constant of the
MotionControl power controller
0 … 9999 Dependent on
size
