10 Parameter List
150 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
3-8-1-2 Analog Input 1 Function Function of analog input1. Internal
operating values cannot be used as an
actual value source.
▪ No Function
▪ Setpoint/Control Value (Auto)
▪ Control Value (Manual)
▪ Suction Pressure
▪ Discharge Pressure
▪ Differential Pressure
▪ Flow rate
▪ Level
▪ Temperature
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
▪ Differential Pressure_Internal
No Function
3-8-1-3 Analog Input 1 Lower
Limit
Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-1-4 Analog Input 1 Upper
Limit
Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-1-5 Calibration Calibration function of the analog input.
After executing the parameter, 2calibration
points can be set for the analog input.
3-8-2 Analog Input 2
3-8-2-1 Analog Input 2 Signal Sensor signal at analog input 2 ▪ OFF
▪ 4-20 mA
▪ 2-10 V
▪ 0-20 mA
▪ 0-10 V
OFF
