KSB PumpDrive 2 - Page 151

10 Parameter List PumpDrive 2
151 of
212
Parameter Description Help text Possible settings Unit Factory setting
3-8-2-2 Analog Input 2 Function Function of analog input2. Internal
operating values cannot be used as an
actual value source.
▪ No Function
▪ Setpoint/Control Value (Auto)
▪ Control Value (Manual)
▪ Suction Pressure
▪ Discharge Pressure
▪ Differential Pressure
▪ Flow Rate
▪ Level
▪ Temperature
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
▪ Differential Pressure_Internal
▪ DIFF (AI1, AI2)
▪ MIN (AI1, AI2)
▪ MAX (AI1, AI2)
▪ AVE (AI1, AI2)
No Function
3-8-2-3 Analog Input 2 Lower
Limit
Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-2-4 Analog Input 2 Upper
Limit
Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-2-5 Calibration Calibration function of the analog input.
After executing the parameter, 2calibration
points can be set for the analog input.
3-8-3 Analog Input 3
3-8-3-1 Analog Input 3 Signal Sensor signal at analog input 3 of the I/O
extension board
▪ OFF
▪ 4-20 mA
▪ 2-10 V
▪ 0-20 mA
▪ 0-10 V
OFF
