10 Parameter List
152 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
3-8-3-2 Analog Input 3 Function Function of analog input3 of the I/O
extension board. Internal operating values
cannot be used as an actual value source.
▪ No Function
▪ Setpoint/Control Value (Auto)
▪ Alternative Setpoint/Control Value
(Auto)
▪ Control Value (Manual)
▪ Suction Pressure
▪ Discharge Pressure
▪ Differential Pressure
▪ Flow Rate
▪ Level
▪ Temperature
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
▪ Differential Pressure_Internal
No Function
3-8-3-3 Analog Input 3 Lower
Limit
Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-3-4 Analog Input 3 Upper
Limit
Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-3-5 Calibration Calibration function of the analog input.
After executing the parameter, 2calibration
points can be set for the analog input.
3-8-4 M12 Module Input A
3-8-4-1 Function M12 Module
Input A
Function of M12 module, inputA. Internal
operating values cannot be used as an
actual value source.
▪ OFF
▪ Suction pressure
▪ Discharge pressure
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
OFF
3-8-4-2 Lower Limit M12
Module Input A
Only relevant for analog inputs Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-4-3 Upper Limit M12
Module Input A
Only relevant for analog inputs Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-4-4 Calibration Calibration function of the M12 module.
After executing the parameter, 2calibration
points can be set for the M12 module.
