KSB PumpDrive 2 - Page 153

10 Parameter List PumpDrive 2
153 of
212
Parameter Description Help text Possible settings Unit Factory setting
3-8-5 M12 Module Input B
3-8-5-1 Function M12 Module
Input B
Function of M12 module, input B. Internal
operating values cannot be used as an
actual value source.
▪ OFF
▪ PMtr Suction/Discharge Pressure
▪ PMtr Suction/Discharge
Pressure_Internal
▪ Suction pressure
▪ Discharge pressure
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
OFF
3-8-5-2 Lower Limit M12
Module Input B
Only relevant for analog inputs Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-5-3 Upper Limit M12
Module Input B
Only relevant for analog inputs Minimum to maximum limit of value range
set
Dependent on the
unit set
3-8-5-4 Calibration Calibration function of the M12 module.
After executing the parameter, 2calibration
points can be set for the M12 module.
3-8-6 Digital Inputs
