10 Parameter List
164 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
3-8-8-4 Assignment 4 Analog
Output 2
Selectable assignment 4 of analog output2
of I/O extension board
▪ OFF
▪ Setpoint
▪ Actual Value
▪ Motor Speed
▪ Motor Power
▪ Motor Current
▪ Motor Voltage
▪ Output Frequency
▪ DC Link Voltage
DC Link Voltage
3-8-8-5 Analog Output 2 Signal Signal type at analog output 2 "4-20 mA2-10 V" 4-20 mA
3-8-8-6 Calibration of Current
Signal
Calibration function of the analog output.
After executing the parameter, 2calibration
points can be set for the analog output.
3-8-8-7 Calibration of Voltage
Signal
Calibration function of the analog output.
After executing the parameter, 2calibration
points can be set for the analog output.
3-8-9 Relay Output 1
3-8-9-1 Relay 1 Function Selectable messages via relay 1 ▪ No function
▪ AUTO operating mode
▪ RUN operating status
▪ AUTO/SLEEP operating status
▪ Warning
▪ Alert
▪ Alert or Warning
▪ No alert
▪ Dynamic overload protection
▪ Current too high
▪ Current too low
▪ Frequency too high
▪ Frequency too low
▪ Power too high
▪ Power too low
▪ Actual value = setpoint
Alert
