10 Parameter List
176 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
3-9-6 Dry Running Detection
3-9-6-1 Hydraulic Blockage Limit Factor for shifting the learning curve. The
limit curve for hydraulic blockage is
calculated based on the product of the
learning curve with the parameter.
0 … 130 % 110
3-9-6-2 Dry Run Time Limit Factor for shifting the learning curve. The
limit curve for dry running is calculated
based on the product of the learning curve
with the parameter.
0 … 130 % 85
3-9-6-3 Start Learning Function When the learning function is run, the
frequency inverter activates 5speed points
and saves the associated mechanical power
values. For this purpose, it must be ensured
that discharge-side valves are fully closed.
Run
3-9-6-4 Mech. Power at n_min Mechanical power at speed 1 (minimum
speed) from learning function for Q = 0 m³/
h
Minimum to maximum limit of value range
set
Dependent on the
unit set
0,00
3-9-6-5 Mech. Power at n_2 Mechanical power at speed 2 from learning
function for Q = 0 m³/h
Minimum to maximum limit of value range
set
Dependent on the
unit set
0,00
3-9-6-6 Mech. Power at n_3 Mechanical power at speed 3 from learning
function for Q = 0 m³/h
Minimum to maximum limit of value range
set
Dependent on the
unit set
0,00
3-9-6-7 Mech. Power at n_4 Mechanical power at speed 4 from learning
function for Q = 0 m³/h
Minimum to maximum limit of value range
set
Dependent on the
unit set
0,00
3-9-6-8 Mech. Power at n_max Mechanical power at speed 5 from learning
function for Q = 0 m³/h
Minimum to maximum limit of value range
set
Dependent on the
unit set
0,00
3-9-6-9 Hydraulic Blockage
Warning Time Delay
Time delay before the hydraulic blockage
warning is triggered
0,0 … 600,0 s 60,00
3-9-6-10 Hydraulic Blockage Alert
Time Delay
Time delay before the hydraulic blockage
alert is triggered
0,0 … 600,0 s 120,00
3-9-6-11 Dry Running Alert Time
Delay
Time delay before the dry running alert is
triggered
0,0 … 600,0 s 5,0
3-9-7 External Dry Running
Detection
3-9-7-1 External Dry Running
Detection Behaviour
Alarm behaviour of external dry running
detection
▪ Self-acknowledging
▪ Non-self-acknowledging
Non-self-
acknowledging
3-9-8 Flow Rate Estimation
3-9-8-1 Flow Rate Estimation Activation of flow rate estimation ▪ OFF
▪ ON
ON
