Lubrication Schedule
5-17
KVAL 994-X Operation/Service Manual
Lubrication Schedule
KVAL recommends the following lubrication schedule to ensure that the machine operates prop-
erly.
TABLE 5- 3. Recommended Lubrication Schedule
Type of Assembly Recommended Schedule Recommended Lubrication Type
Linear Bearing
Every 250 Hours of Machine Operation Dura-Lith Grease (KV
AL P/N
Lube EP-2)Pillow Block Bearing
Flange Block Bearing
Ball Screw Every 80 Hours of Machine Operation
Air Line Lubricator One drop of oil every 2 or 3 cycles
Check the lines every week to two weeks
Note: Some CNC Machines drop every 5-10
cyc
les.
E
ither lubricant listed below is approved
to use.
• KVAL P/N SYSLUBG
• Chevron AW Hydraulic Oil 32
• G-C lubricants light AW R&O
• Mobile DTE 24
• Shell Tellus32
• Gulf Harmony 32
Gear Box 2000 Hours of Machine Operation or six months
of operation
• AGMA #8 gear lube
• MOBILUBE HD 80 W-90
• or equivalent
