Back Section:
KVAL 994-X Operation/Service Manual
2-22
Back View of Rear Section
Bolt Drill Extend and
Retract Cylinder
Face Plate Motor and Bit:
Routs face plate.
Bolt Drill Motor:
Machines lock
plate on the side of
the door
Lock Bore Limit Switches
Deep
Shallow
Retracted
Lock Bore Oil
Reservoir
