KVAL 994-X Operation/Service Manual
About this Manual
This manual contains operation information and service and maintenance information.
It includes identification of machine assemblies, power-up and power-down steps, and informa-
tion about using the user interface.
The Troubleshooting and Maintenance sections are directed toward qualified service
technicians
TABLE 1- 2.
Title Part Number
994-X Operation and Service Manual DOC-204_2-OPS
Narrow Door Support Supports doors between 12" - 16”
Structure utilizes air cylinder
s and 7 pairs of industrial wheels for sup-
port - mecha
nism is automatically put in and out of position via a
selection
Split Ja
mb Staplers Two 1/4" crown staple guns are mounted onto the jamb clamp brack-
ets. While clamped in the machine, staples will be driven into the back
si
de of the split jamb to kee
p the male and female together.
The staple guns are fired with a single valve that is interlocked with a
safety switch to disa
ble the staple guns unless there is a jamb clamped
in the machine.
Two staple guns with remote fires are requir
ed and are not included
in
the price of the option.
