Kval 994-X - Connections to Servo Drives

Network System Overview
KVAL 994-X Operation/Service Manual
6-32
Connections to Servo Drives
The Servo Drives are located in the Main Electrical Panel. The figure below, shows a typical
servo drive layout.:
For detailed wiring information, see your machine’s electrical drawings.
24 VDC Input
Ether CAT Output
Ether CAT
Input
(From
PLC)
High
Voltage
Input
Servo
Drive 1
2 High Voltage
Servo Drive 2
2 High Voltage
Outputs
Servo Drive 3
2 High Voltage
Servo Drive 4
2 High Voltage
Servo Drive 5
2 High Voltage
Outputs
Servo Drive 6
2 High Voltage
Outputs
Servo Drive 7
1 High Voltage
Output
FIGURE6- 40. Servo Drives
