Option SB: About the CNC Back Section Operator Screens
2-53
KVAL 994-X Operation/Service Manual
Option SB: About the CNC Back Section Operator Screens
The CNC Backsection adds some unique features that add more choices to the Operator Screens.
This section details the added features to the operator screens,
Note: To read about all menu choices, see “Description of User Interface Screens” on
page 2-36 .
Option SB: Main Menu Screen
The following is added to the Main Screen in the CNC Back Section option.
Square Plate: Tog-
gle to turn the
square plate cutting
routine ON or OFF
Lock Plate: Adjust
Lock Plate ti the X, Y
and Z specifications
To Next Page
