Location of Sensors on 994-X
KVAL 994-X Operation/Service Manual
6-22
Location of Sensors on 994-X
Figure 6- 36 below, shows the sensor locations on the 994-X The “I” designation represents an
input to the PLC and the “Q” designation represents an output from the PLC.
Inside of
Fence
Outside Of
Fence
Narrow Door Outside
(Option)
Narrow Door Inside
(Option)
Door Sense Eye
Before In-Feed
Stop
Door In
Machine
After Out Feed
Stop Eye
After In-Feed
Stop
Width Adjust-
ment Sensors
Valve Bank 1
Q Designators
Width Adjust-
ment Sensors
Valve Bank 2
Q Designators
Valve Bank 3
Q Designators
Before Out
F e e d S t o p E y e
FIGURE6- 36. Location of Sensors Top View 994-X
