Front Section
KVAL 994-X Operation/Service Manual
2-8
Front Section
The Front Section contains:
• Operator Station
• Six Shooter
• Opt K: adds an Eight Shooter
• Opt V: adds narrow door support.
• Machine Control
• Hinge Carriages 1 through 4
Hinge Carriage # 1 Hinge Carriage # 2 Hinge Carriage # 3
Hinge Carriage # 4
Six Shooter:
Opt Z: Quick
Change
Machine Control
Opt K: Eight
Shooter
(Opt V) Narrow Door Support:
Supports Doors under 16.0'' for
either Hinge or Lock Side
Standard: Pre Drill, Router
Opt CR: adds CR Router
Opt CH: adds Chisels, 4 corners
FIGURE 2- 7. View of Front Section
