Kval 994-X - High Frequency Panel

About the Electrical Panels
KVAL 994-X Operation/Service Manual
2-28
High Frequency Panel
The High Frequency Panel
• Supplies voltages to the machine
• Contains the PLC interface
• VFDs (Variable Frequency Drives) to interact with hinge and faceplate routers,
width adjust motors, and feed motors
Contactors, Thermal Overload
and Control Transformer
Lock Bore Motor
Bolt-Drill Motor
6- Shooter screw Driver
In-Feed Ball Catch (Opt BC)
Out-Feed Ball Catch (Opt BC)
8- Shooter Screw Driver (Opt K)
110 V / 24 V Terminals
High Voltage Section
Input / Output
Terminals
VFD Section
Hinges 1-4
Face Plate Router
Feed Motor
Width Adjust
Pre-Drill 1-4
Counter Rotate Router 1-4 (Opt CR)
High Frequency Panel
FIGURE 2- 18.
