Location of Sensors on 994-X
6-23
KVAL 994-X Operation/Service Manual
Z Axis and Y Axis Front Section Sensors
Figure 6- 37 below shows the placement of the Z-Axis sensors and the Y-Axis sensors. The Y-Axis
sensors sets the maximum limits in positive and negative vertical movement and also sets the
home position. The Z-Axis sensors sets the maximum limits in positive and negative depth move-
ment and also sets the home position.
Y- Ax is H ome Eye
Y-Axis Forward Crash Eye
Y-Axis Reverse Crash Eye
Z- Axi s H om e E ye
Z-Axis Forward Crash Eye
Z-Axis Reverse Crash Eye
FIGURE6- 37. Figure 6- 37 Section View of 994-X Y and Axis Sensors
