Replacing Tooling in the Front Section
5-25
KVAL 994-X Operation/Service Manual
.
5. Move the Six-Shooter assembly away from the machine-it will move about 1½ inch.
This provides room for hands to access the screwdriver bit holders.
6. To remove screwdriver bit, push the bit holder (see images) back toward the Six-
Shooter assembly and hold: pull bit out of holder.
7. To insert screwdriver bit, push bit holder back toward Six-Shooter assembly and
hold while inserting new bit. Release holder to secure bit.
8. Move Six-Shooter assembly back toward machine and pull the back slide toward
you; then move assembly away from machine to restore assembly to original start-
ing position
