KVAL 990-H Operation / Service Manual 1
Numerics
110V / 24 V terminals
location electrical panels
2-28
994-X
description of machine
2-2
A
additional functions
user interface descriptions
2-50
adjustment menus
how to use
3-8
air line lubricator, maintenance schedule5-17
auto enable/disable buttons
description
2-42
B
back section
checking specs
3-17
key assemblies2-21
menu path to calibration3-17
back section group
description
2-41
back section status
feedback
2-36
ball screw, maintenance schedule5-17
base
readout description
3-8
Beckhoff® CPU module4-2
bit assemblies
how to access
5-22
bits
replacing
5-21, 5-26
C
Calibration
enter a positive of negative number?
3-7
calibration
description
3-2
flowchart3-3
front section assemblies3-4
lock location3-17
path to hinge setup3-8
pre-drill3-13, 3-15, 3-20
slot dimensions3-5
steps before3-2
suggested order of steps3-9
chisels
remove and replace
5-24
collet assembly
inspection
5-23, 5-26, 5-27
combine with base
how to use
3-8
computer
as a PLC
4-2
backing up4-2, 4-3
control panel light
not on? troubleshoot
6-28
control power indicator light description2-29
control transformer switch
power up
2-33, 2-34
D
diagnostic screen
description
2-52
door spec group
description
2-41
dura-lith grease, bearing lube5-17
DVI/USB module location4-2
E
electrical panels
description
2-27
emergency shutdown
description
2-35
e-stop light
description
2-29
EtherCat®
smart power supply
4-2
terminals,location4-2
ethernet module
connection to servo amplifiers
4-2
F
feed system timing
description
2-44
flange block bearing, maintenance schedule5-17
front section
key assemblies2-9
front section status
feedback
2-36
