Group 8 Job Editor Page 259
JET3 Series Release 2.02
Pos.
Print mode
Annotation
1
2-line 7 dot high speed
2
5 dot high speed
3
12 dot high speed
4
16 dot fast
5
16 dot speed
6
24 dot high speed barcode
7
24 high speed
8
24 dot fast
9
24 dot high quality
10
32 dot high speed
11
32 dot fast
12
32 dot high quality
ATTENTION
The number of vertical dots of the print mode selected has to be greater
or equal than the number of vertical dots of the selected font matrix.
Inappropriate print modes may result in incomplete printouts.
A mismatch between the selected print mode and the selected font matrix
can be identified in the preview shown in the editing area of the Job editor.
Example for a selected font matrix of 12x 8 (12 dots in height and 8 dots in width):
Previews in the editing area of the job editor
Non-printable area
Selection 16 dots
Selection 7 dots
Appropriate print mode
Inappropriate print
mode
