Leibinger JET3 Series - Print Parameter; Figure 140 - Print Parameter

Page 260 Job Editor Group 8
Release 2.02 JET3 Series
8.5.2 Print parameter
The <Print Parameter > tab provides parameters for the the kind of text output, the
PrintGo source and several monitoring functions in combination with sensor evealuations.
List of available settings:
 PrintGo-Delay
 Monitoring and control functions
 PrintGo-Distance
 PrintGo length
 PrintGo-Repeat
 PrintGo tolerance
 PrintGo-Holdoff Distance
 Drop Flighttime
 PrintGo Source
 PrintGo-Gate
Important
The Printer printer works with an internal shift register for PrintGo signals. Up
to 8 PrintGo signals are buffered. This allows distances between the products
to be printed on which are shorter than the length of a single product.
Note:
Because of the size of the buffer the shift register will only work properly as
long as there are not more than 8 products between the PrintGo sensor and
the printhead.
Figure
140
Print parameter tab
1 – PrintGo delay settings
7 – PrintGo length settings
2 – PrintGo distance settings
8 – PrintGo tolerance settings
3 – PrintGo repeat settings
9 – Drop-Flighttime compensation
4 – PrintGo Holdoff distance settings
10 – PrintStop settings
5 – PrintGo Source settings
11 – PrintGo gate settings
6 – Print control settings
1
2
6
7
3
4
5
8
9
10
11
