Leibinger JET3 Series - Interface Connections Overview

Group 5 Transport/Start up Page 51
JET3 Series Release 2.02
Figure
11
Filling routine (Step 2)
Message during the routine
9 – Message <Fill up Routine finished>
13 – <OK> Button
10 – <OK> Button
14 – Main window
11 – <Close> Button
15 – Message <Bleeding>
12 – Message <Hydraulic control>
16 – Button <Cancel>
14
12
10
13
11
15
16
9
