Page 44 Transport/Start up Group 5
Release 2.02 JET3 Series
5.4 Start-up Commissioning
For a safe transport some hydraulic components are supplied with transportation protection
(cable ties) and the reservoir tanks are evacuated. The following steps have to be carried
out before the initial operation
 Remove the transportation protection (cable ties) (Step 1)
 Fill the reservoir tank (Step 2)
 Carry out the function <Filling Routine> (Step 3)
5.4.1 Remove transportation safety devices - Step 1
The pumps and valves of the hydraulic system are secured with cable ties. These have to be
absolutely removed.
Proceeding:
 Dismantle the backplane of the hydraulic cabinet (1) by loosing the fixing screws (2).
ATTENTION
The cable tie at the main filter (3) should not be removed!
 Remove the transportation protection (cable ties).
 Now attach the backplane of the hydraulic cabinet again with the according fixing screws.
