The Ethernet-connection is implemented with a sturdy M12D coded socket and is designed
for high transfer rates and long cable lengths. It provides the networking of several devices
in multi-head applications. The data exchange happens via the „Leibinger interface
protocol“.
The interface X5 provides the connection of an external PrintGo-signal. All common product
detectors (e.g. light barrier, product sensor ect.), 24V NPN- as well as 24V PNP-switching
can be connected. The PrintGo Gate input requires a PNP sensor!
Regarding the software you can select additionally if the positive edge or the negative edge
should be used for the release of the printout.
Note:
The PrintGo signal is the starting signal for the print start of the printer
.
