Leibinger JET3 Series - Printgo-Delay; Printgo-Distance; Figure 141 Printgo-Delay; Figure 142 Printgo-Distance

Group 8 Job Editor Page 261
JET3 Series Release 2.02
8.5.2.1 PrintGo-delay
With this setting a delay of the printout is set. The delay is specified in the dimension set
in the <Basic settings> e.g. in mm.
The PrintGo delay defines the distance between the PrintGo signal and the beginning of
the printout.
The current delay is shown in the respective input field.
Figure
141
PrintGo-delay
Start of the printout beginning
PrintGo signal
8.5.2.2 PrintGo-distance
The <PrintGo distance> defines the distance between the printouts. The delay is
specified in the dimension set in the <Basic settings> e.g. in mm.
The referenc point for the distance measurement is the beginning of the printout.
The current value is shown in the respective input field.
This parameter is important in combination with the <Repetition> paramenters.
Figure
142
PrintGo-distance
ATTENTION
If the PrinteGo distance is shorter than the printouts the printouts will be
pushed together or overlapping. Additionally an inappropriate PrintGo
distance may cause Print distance error messages.
Example for a wrong PrintGo distance setting:
Print-Go distance too small
Print-Go distance correct
1. Printout
1. Repetition
PG-S = PrintGo signal
PG-D = PrintGo distance
The PrintGo distance between the first
printout and the first repetition is shorter
than the printout itself. Therefore the
printouts will be pushed together or
overlapping.
PrintGo delay
PrintGo - distance
Printout 1
Printout 2
PrintGo - distance
Printout 3
PG-S
PG-D
