Group 5 Transport/Start up Page 47
JET3 Series Release 2.02
Proceeding (Example: Filling of solvent)
Risk of fire and injury! Absolutely observe!
Before filling the device with the consumables, measures for the
electrostatic discharge have to be made!
Highly flammable! Burning gases and liquids may cause severe burns.
Keep sources of ignition away from the printer!
Always statically discharge the printer and yourself before filling the
reservoirs! Simply touch the housing of the printer to discharge the
equipment and stand on a grounded surface wearing ESD shoes during
filling!
Protective equipment is necessary! Read the safety data sheets and the
personal protective equipment rules and regulations!
The sealing of the refill bottle must not be opened!
Open the lid (2) of the reservoir tank unit (1).
Open the screw cap of the solvent tank (4) and of the refill bottle (5).
Put the refill bottle on the solvent tank. The seal of the bottle will be breached and the
closing valve of the tank will open automatically and the reservoir tank is filled up.
Wait until the refill bottle is completely empty.
Take out the empty refill bottle. The closing valve of the reservoir tank will be closed
automatically.
Finally close the reservoir tank and empty refill bottle carefully with the srew caps.
The reservoir tanks as well as the empty refill bottles have to be closed
carefully after filling.
