9400 regenerative power supply module | Parameter setting
Diagnostics & fault analysis
Device diagnostics via keypad/bus system
Identification data
The parameters in the following table, which are grouped in the Identification
Regenerative power supply module category in the »Engineer« parameter list and in the
keypad, serve to display the identification data of the regenerative power supply module:
C00055/4 Phase current phase W - A
C00061 Heatsink temperature - °C
C00062 Temperature inside the controller - °C
C00063 Filter temperature - °C
C00068 Capacitor temperature - °C
C00069 CPU temperature - °C
C00134 Minimum brake resistance - Ohm
C00137 Brake chopper utilisation - %
C00138 Brake resistor utilisation - %
C00443/1...8 Status: Digital inputs -
C00444/1...4 Status: Digital outputs -
Parameter Display
C00099 Firmware version
C00200 Firmware product type
C00201 Firmware compilation date
C00203/1...9 HW product types
C00204/1...9 HW serial numbers
C00205/1...6 HW descriptions
C00206/1...6 HW manufacturing data
C00208/1...6 HW manufacturer
C00209/1...6 HW countries of origin
C00210/1...6 HW versions
C02113 Program name
Parameter Information Lenze setting
Value Unit
