9400 regenerative power supply module | Parameter setting
Diagnostics & fault analysis
Error messages
8.6.1.1 Response
The state of the internal device control changes according to the selected response to an
error, sets controller inhibit and switches on the "DRIVE ERROR" LED at the front of the
regenerative power supply module:
8.6.1.2 Instance ID
The instance ID is dynamically assigned by the operating system.
Bit 31 Bit 30 Bit 29 Response
0 0 0 0: No response
0011: Fault
0102: Trouble
0113: -
1 0 0 4: Warning locked
1015: Warning
1106: Information
1 1 1 7: System fault
Response Logbook entry Display under
C00168
Pulse inhibit Controller inhibit Acknowledge-
ment required
"DRIVE ERROR"
LED
None OFF
Fault 
Trouble 
(after 0.5 s)
Warning locked  
Warning 
Information  OFF
System fault Mains
switching
is required!
Bit 31 1625262829 015
Bit 28 Bit 27 Bit 26 Meaning
0 0 0 Instance ID 0
0 0 1 Instance ID 1
0 1 0 Instance ID 2
0 1 1 Instance ID 3
1 0 0 Instance ID 4
1 0 1 Instance ID 5
1 1 0 Instance ID 6
1 1 1 Instance ID 7
Bit 31 1625262829 015
