EDS94ARNExxxx EN 2.3 - 06/2014 L 341
9400 regenerative power supply module | Parameter setting
Parameter reference
Table of attributes
10.3 Table of attributes
The table of attributes contains information required for communicating with the
regenerative power supply module via parameters.
How to read the table of attributes:
Attribute table
Column Meaning Entry
Code Parameter name Cxxxxx
Name Short parameter text (display text) Text
Index dec Index under which the parameter is addressed.
The subindex of an array variable corresponds to
the Lenze subcode number.
24575 - Lenze code number Only required for access via bus
system.
hex 5FFF
h
- Lenze code number
Data DS Data structure E Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA Number of array elements (subcodes) Number
DT Data type BITFIELD_8 1 byte bit-coded
BITFIELD_16 2 bytes bit-coded
BITFIELD_32 4 byte bit-coded
INTEGER_8 1 byte with sign
INTEGER_16 2 bytes with sign
INTEGER_32 4 byte with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 bytes without sign
UNSIGNED_32 4 bytes without sign
VISIBLE_STRING ASCII string
Factor Factor for data transmission via bus system,
depending on the number of decimal positions
Factor 1 ≡ no decimal positions
10 ≡ 1 decimal position
100 ≡ 2 decimal positions
1000 ≡ 3 decimal positions
Access R Read access Reading allowed
W Write access Writing allowed
CINH Controller inhibit required Writing only possible when controller is inhibited
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
C00002
Device commands 24573 5FFD E 1 UNSIGNED_32 1
C00003
Device command status 24572 5FFC E 1 UNSIGNED_32 1
C00004
Service password 24571 5FFB E 1 UNSIGNED_32 1
C00005
Application selection 24570 5FFA E 1 INTEGER_32 1
C00006
Selected control scheme 24569 5FF9 E 1 UNSIGNED_8 1
C00007
Active application 24568 5FF8 E 1 INTEGER_32 1
C00018
Chopper frequency 24557 5FED E 1 UNSIGNED_32 1
C00022
Maximum current 24553 5FE9 E 1 UNSIGNED_32 100
C00034
Config. analog input 1 24541 5FDD E 1 UNSIGNED_32 1
C00050
Output power (DC) 24525 5FCD E 1 INTEGER_32 10
C00051
Mains frequency 24524 5FCC E 1 INTEGER_32 10
C00052
Mains voltage 24523 5FCB E 1 UNSIGNED_32 1
C00053
DC-bus voltage 24522 5FCA E 1 UNSIGNED_32 1
C00054
Line current 24521 5FC9 E 1 UNSIGNED_32 100
C00055
Phase currents 24520 5FC8 A 4 INTEGER_32 100
