9400 regenerative power supply module | Parameter setting
Parameter reference
Table of attributes
342 L EDS94ARNExxxx EN 2.3 - 06/2014
C00057 Maximum effective power 24518 5FC6 E 1 INTEGER_32 10
C00061
Heatsink temperature 24514 5FC2 E 1 INTEGER_32 1
C00062
Temperature inside the controller 24513 5FC1 E 1 INTEGER_32 1
C00063
Filter temperature 24512 5FC0 E 1 INTEGER_32 1
C00064
Device utilisation (Ixt) 24511 5FBF E 1 UNSIGNED_32 1
C00065
Ext. 24-V voltage 24510 5FBE E 1 INTEGER_32 10
C00068
Capacitor temperature 24507 5FBB E 1 INTEGER_32 1
C00069
CPU temperature 24506 5FBA E 1 INTEGER_32 1
C00070
DC bus voltage ctrl. gain 24505 5FB9 E 1 UNSIGNED_32 100000
C00071
DC bus voltage ctrl. reset time 24504 5FB8 E 1 UNSIGNED_32 10
C00075
Current controller gain 24500 5FB4 E 1 UNSIGNED_32 100
C00076
Current contr. reset time 24499 5FB3 E 1 UNSIGNED_32 100
C00084
Filter resistance 24491 5FAB E 1 UNSIGNED_32 10000
C00085
Filter inductance 24490 5FAA E 1 UNSIGNED_32 1000
C00099
Firmware version 24476 5F9C E 1 VISIBLE_STRING 1
C00114
Dig. input x: Terminal polarity 24461 5F8D A 8 UNSIGNED_8 1
C00118
Dig. output x: Terminal polarity 24457 5F89 A 4 UNSIGNED_8 1
C00121
Filter temp. warning threshold 24454 5F86 E 1 UNSIGNED_32 1
C00122
Heatsink temp. warn. threshold 24453 5F85 E 1 UNSIGNED_32 1
C00123
Warning threshold device util. 24452 5F84 E 1 UNSIGNED_32 1
C00126
CPU temp. warning threshold 24449 5F81 E 1 UNSIGNED_32 1
C00129
Brake resistor value 24446 5F7E E 1 INTEGER_32 10
C00130
Rated power of brake resistor 24445 5F7D E 1 INTEGER_32 1
C00131
Therm. capacity brake resistor 24444 5F7C E 1 INTEGER_32 1
C00132
Activation brake chopper 24443 5F7B E 1 UNSIGNED_8 1
C00133
Ref.: Brake chopper utilisation 24442 5F7A E 1 UNSIGNED_8 1
C00134
Minimum brake resistance 24441 5F79 E 1 INTEGER_32 10
C00137
Brake transistor utilisation 24438 5F76 E 1 INTEGER_32 1
C00138
Brake resistor utilisation 24437 5F75 E 1 INTEGER_32 1
C00142
Autom. restart after mains ON 24433 5F71 E 1 UNSIGNED_32 1
C00143
Sampled peak power 24432 5F70 A 3 UNSIGNED_32 10
C00144
Time stamp of sampled max. power 24431 5F6F A 3 UNSIGNED_32 1
C00145
Energy out 24430 5F6E A 2 INTEGER_32 1000
C00150
Status word device control 1 24425 5F69 E 1 BITFIELD_16 1
C00155
Status word device control 2 24420 5F64 E 1 BITFIELD_16 1
C00156
Status/Control word ECTRL 24419 5F63 A 2 UNSIGNED_32 1
C00158
Controller inhibit by (source) 24417 5F61 E 1 BITFIELD_16 1
C00162
Masked error number 24413 5F5D A 3 UNSIGNED_32 1
C00166
Error description 24409 5F59 E 1 VISIBLE_STRING 1
C00168
Error number 24407 5F57 E 1 UNSIGNED_32 1
C00169
Logbook - event filter 24406 5F56 E 1 BITFIELD_32 1
C00173
Mains voltage 24402 5F52 E 1 UNSIGNED_8 1
C00178
Elapsed hour meter 24397 5F4D E 1 UNSIGNED_32 1
C00179
Power-on time meter 24396 5F4C E 1 UNSIGNED_32 1
C00180
Service code 24395 5F4B E 1 VISIBLE_STRING
C00181
Red. brake chopper threshold 24394 5F4A E 1 UNSIGNED_32 1
C00183
Device state 24392 5F48 E 1 UNSIGNED_32 1
C00186
ENP: Identified filter type 24389 5F45 E 1 VISIBLE_STRING 1
C00187
ENP: Identified serial number 24388 5F44 E 1 VISIBLE_STRING 1
C00188
ENP: Status 24387 5F43 E 1 UNSIGNED_8 1
C00199
Device name 24376 5F38 E 1 VISIBLE_STRING 1
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
