Lexmark XC4150 - Right Cover Removal

4 Remove the three screws (C) from the rear of the cover, and then remove the cover.
C
Right cover removal
1 Remove the motor cover. See “Motor cover removal” on page 319.
2 Remove the scanner rear left cover. See “Scanner rear left cover removal” on page 335.
7528
Repair information
318
