Lexmark XC4150 - LVPS Controller Board Connectors

575 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Loading...

Connector Connects to Pin no. Signal

JFAX Fax modem 1 BSPI_CS-

2NC_FAXBUZZER_R

3BSPI_RXD

4GND

5BSPI_TXD

6GND

7BSPI_CLK

8GND

9SPI_IRQ-

10 +5V_RIP

11 FAX_POR_R

12 +3.3v

13 +3.3v

14 TONE

LVPS controller board connectors

CN 201

CN 1

AC 1

7528

Component locations

473
