Lexmark XC4150 - Control Panel Tub Mounting Bracket Removal

5 Remove the two screws (C).
C
6 Tilt up the control panel tub, and then lift to remove.
Control panel tub mounting bracket removal
1 Remove the control panel bezel. See “Control panel bezel removal” on page 337.
2 Remove the lower control panel bezel. See “Lower control panel bezel removal” on page 336.
3 Remove the control panel. See “Control panel removal” on page 337.
4 Remove the control panel tub. See “Control panel tub removal” on page 338.
7528
Repair information
339
