Lexmark XC4150 - Cleaning the Printhead Lenses

2 Wipe the areas shown with a damp, soft, lint-free cloth.
1 White underside of the scanner cover
2 Scanner glass
3 Automatic document feeder (ADF) glass
4 White underside of the ADF cover
3 Close the scanner cover.
Cleaning the printhead lenses
1 Remove the waste toner bottle.
2 Remove the imaging kit.
3 Using a lint-free cloth, wipe the printhead lenses (A).
A
7528
Maintenance
483
