5 Disconnect the sensor cable (B), and then remove the sensor.
B
Deskew rollers removal
1 Open the front door.
2 Remove the right cover. See “Right cover removal” on page 318.
3 Remove the left cover. See “Left cover removal” on page 316.
4 Remove the LVPS. See “LVPS removal” on page 359.
5 Remove the sensor (media type). See “Sensor (media type) removal” on page 394.
6 Remove the sensor (input). See “Sensor (input) removal” on page 395.
7528
Repair information
396
