Lexmark XC4150 - TPS Wiper Removal

To Next Page

To Previous Page

8 Slide the shaft out, and then remove the TPS wiper mechanism.

TPS wiper removal

1 Remove the TPS sled. See “TPS sled removal” on page 381.

2 Remove the three wipers (A) from the sled.

7528

Repair information

386
