Lexmark XC4150 - Speaker Removal

Speaker removal
1 Remove the scanner front cover. See “Scanner front cover removal” on page 434.
2 Disconnect the speaker connector (A), and then remove the two screws (B).
B
A
3 Remove the speaker.
ADF top cover removal
1 Open the ADF top cover.
Note: Pay attention to the position of the tabs (A).
7528
Repair information
431
