Lexmark XC4150 - Sensor (550-Sheet Tray Index) Removal

Sensor (550-sheet tray index) removal
1 Remove the tray insert.
2 Remove the paper feeder. See “550-sheet tray right cover removal” on page 444.
3 Remove the screw (A).
A
4 Disconnect the two cables (B), and then cut the zip tie (C).
CB
7528
