8 Remove the cable (F) from the right control panel arm.
F
Duplex removals
Duplex inner guide removal
1 Remove the front cover. See “Front cover removal” on page 309.
2 Remove the pivot shaft. See “Pivot shaft removal” on page 345.
7528
Repair information
343
