Lexmark XC4150 - Sensor (550-Sheet Tray Pass-Through) Removal

3 Disconnect the cable (C).
C
4 Remove the paper feeder.
Sensor (550-sheet tray pass-through) removal
1 Remove the tray insert.
2 Remove the screw (A), and then disconnect the cable (B).
A
B
3 Remove the sensor.
7528
Repair information
448
