Control panel bezel removal
1 Carefully pull the lower left corner of the bezel to disengage it.
2 Remove the bezel.
Control panel removal
1 Remove the control panel bezel. See “Control panel bezel removal” on page 337.
2 Remove the lower control panel bezel. See “Lower control panel bezel removal” on page 336.
3 Remove the six screws (A).
A
7528
Repair information
337
