Assembly 2: Covers 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0410 1 1 Output bin extender --
2 41X0433 1 1 Output bin cover
“Output bin cover removal” on
page 330
341X0771 1 1Exit output cover --
4 41X0772 1 1 Output bin flag
“Output bin flag removal” on page
419
541X0570 1 1Sensor (bin full) --
6 41X0435 1 1 Scanner rear right cover
“Scanner rear right cover removal” on
page 334
7 41X0436 1 1 Scanner front cover
“Scanner front cover removal” on
page 434
841X0429 1 1Top frame cover
“Top frame cover removal” on
page 331
9 41X0430 1 1 Top frame base cover
“Top frame base cover removal” on
page 333
10 41X0562 1 1 Right control panel arm
“Control panel arms removal” on
page 340
11 41X0561 1 1 Left control panel arm
“Control panel arms removal” on
page 340
12 41X0432 1 1 Left cover
“Left cover removal” on page 316
13 41X0434 1 1 Scanner rear left cover
“Scanner rear left cover removal” on
page 335
14 41X0438 1 1 Top cover
“Top cover removal” on page 311
NS 41X1009 1 1 External air filter
“External air filter removal” on
page 336
7528
Parts catalog
490
