Introducing the LU600 LiveU LU600 User Guide
Introducing the LU600
Overview
The LU600 is a compact lightweight unit that enables you to transmit high-quality SD/HD
(and with optional HEVC cards, 4K) video from diverse locations, while adapting to dynamic
network conditions. The LU600 provides broadcast-grade video quality and bitrate (20
Mbps), a very high file transfer speed (80 Mbps) and comes with a battery that can provide
up to 4 hours of live streaming.
The LU600 connects seamlessly to most commercially available cameras using either SDI or
HDMI interfaces, and can support up to four audio channels when using SDI.
The LU600 supports 3G/4G (LTE and Advanced LTE) cellular networks, WiFi links and two
Ethernet links.
The LU600 introduces a five-inch capacitive touch screen and a streamlined user interface.
Figure 1: LU600
As the LU600 powers up, it dials (connects) its modems, connects the WiFi / Ethernet
interfaces to various networks and combines their bandwidth into a single consolidated
broadband uplink connection. The LU600 can then encode incoming video into an H.264 (or
HEVC) stream and transmit it over the aggregated bandwidth or use this bandwidth for
DataBridge functionality.
