Chapter 6 Basic Functions
6-7
5) Frequency command by advanced I/O option card
You can input the frequency command by using -10~+10V (V2 terminal) and 0~20mA
(I2terminal) if you mount an extended I/O card on the inverter option slot.
ඖ -10~+10V Input
Group Code No. Function Display Setting Displayed Setting Range Unit
DRV 07 Freq Ref Src 4 V2 - -
IN
35 V2 Monitor - 0.00 0~20 mA
37 V2 Filter - 10 0~10000 msec
38 V2 Volt x1 - 0.00 0~10V V
39 V2 Perc y1 - 0.00 0~100 %
40 V2 Volt x2 - 10.00 0~10 V
41 V2 Perc y2 - 100.00 0~100 %
42 V2 -Volt x1’ - 0.00 0~10 V
43 V2 -Perc y1’ - 0.00 0~100 %
44 V2 -Volt x2’ - -10.00 0~10 V
45 V2 -Perc y2’ - -100.00 -100~0 %
46 V2 Inverting 0 No No/Yes -
47 V2 Quantizing - 0.04 0.04~10 %
The voltage input of the extended I/O inputs bipolar voltage at -10V ~ +10V. Its
operating method is the same as the Bipolar input of the V1 terminal, which was
described on page 6-2 in detailed user’s manual from website.
ඖ0 ~ 20mA Input
Group Code No. Function Display Setting Displayed Setting Range
Unit
DRV 07 Freq Ref Src 5 I2 - -
IN
50 I2 Monitor - 0.00 0~20 mA
52 I2 Filter - 15 0~10000 msec
53 I2 Curr x1 - 4.00 0~20 mA
54 I2 Perc y1 - 0.00 0~100 %
55 I2 Curr x2 - 20.00 4~20 mA
56 I2 Perc y2 - 100.00 0~100 %
61 I2 Inverting - No No/Yes -
62 I2 Quantizing - 0.04 0.04~10 %
See the description of the I1 terminal on Page 6- 6in detailed user’s manual from
website.
