LSIS SV-iS7 series User Manual

Chapter 3 Installation
3-22
3.1.4 Dimension and Weight of frame (UL Enclosed Type 1, IP 21Type)
Inverter
Capacity
W
[mm]
H
[mm]
D
[mm]
EMC&DCL
Weight
[Kg]
Only EMC
Product
weight[Kg]
Only DCL
Product
weight[Kg]
Non EMC
and DCL
Product
weight[Kg]
SV0008iS7-2/4 150 284 200 5.5 4.5 5.0 4.5
SV0015iS7-2/4 150 284 200 5.5 4.5 5.0 4.5
SV0022iS7-2/4 150 284 200 5.5 4.5 5.0 4.5
SV0037iS7-2/4 150 284 200 5.5 4.5 5.0 4.5
SV0055iS7-2/4 200 355 225 10 8.4 9.3 7.7
SV0075iS7-2/4 200 355 225 10 8.4 9.3 7.7
SV0110iS7-2/4 250 385 284 20 17.2 16.8 14
SV0150iS7-2/4 250 385 284 20 17.2 16.8 14
SV0185iS7-2 280 461.6 298 30 27 25.9 22.9
SV0220iS7-2 280 461.6 298 30 25.8 25.9 22.9
SV0300iS7-2 300 570 265.2
- - 29.5
SV0370iS7-2 370 630 281.2
- - 44
SV0450iS7-2 370 630 281.2
- - 44
SV0550iS7-2 46
5
750 355.6
- - 72.5
SV0750iS7-2 46
5
750 355.6
- - 72.5
SV0185iS7-4 280 461.6 298 27.4 23.5 23.3 19.7
SV0220iS7-4 280 461.6 298 27.4 23.5 23.5 20.1
SV0300iS7-4 300.1 594.1 300.4 - - 41 28
SV0370iS7-4 300.1 594.1 300.4 - - 41 28
SV0450iS7-4 300.1 594.1 300.4 - - 41 28
SV0550iS7-4 370 663.4 371. - - 63 45
SV0750iS7-4 370 663.4 371. - - 63 45
SV0900iS7-4 510 783.5 422.6 - - 101 -
