1.2 Names and Uses of Parts
1.2.1 End product (less than 75 kW)
1.2.2 When the front cover is removed (less than 75 kW)
Front cover:
Remove it when wiring
Ke
y
pad
Screw to fix the
front
Wiring bracket
Ground terminal
Coolin
g
FAN
Keypad
connection
Encoder option
Power terminal
Wiring bracket
Communication
option
connection
PLC, extension I/O,
communication
o
p
tion connection
I/O board and terminal
Inverter condition
display BAR
