Chapter 6 Basic Functions
6-12
[Example of speed-8]
If multi-function terminals P5, P6, P7 and P8 are set at Speed-L, Speed-M, Speed-H
and Speed-X respectively, you can operate it as follows.
IN-89 In Check Time: If you use the multi-function terminal for sequential frequency
setting, you can set the in check time for the terminal block input within the inverter. For
example, if you set the in check time at 100msec and input multi-function terminal P6, it
will be checked whether another terminal block input is input for 100msec. After
100msec, it is accelerated or decelerated by the frequency corresponding to P6
terminal.
6.1.5 Operating command setting method
Group Code No. Function Display Initial Display
DRV 06 Cmd Source
0 Keypad
1 Fx/Rx-1
2 Fx/Rx-2
3 Int 485
4 Field Bus
5 PLC
Select the operating command setting method in DRV Group code 06. For operating
command, other than the basic operation using the keypad and multi-function terminal,
you can also use the built-in RS485 communication, Fieldbus and Application Option Card.
Speed FX or RX P8 P7 P6 P5
0 9 - - - -
1 9 - - - 9
2 9 - - 9 -
3 9 - - 99
4 9 - 9 - -
5 9 - 9 - 9
6 9 - 99 -
7 9 - 999
8 99 - - -
9 99 - - 9
10 99 - 9 -
11 99 - 99
12 999 - -
13 999 - 9
14 9999 -
15 99999
