LSIS SV-iS7 series User Manual

Chapter 5 How to Use Keypad
5-4
(4) Monitor Display Items
No Function Display Description
1
Mode
Display
MON Monitor Mode
PAR Parameter Mode
U and M USR & Macro Mode
TRP Trip Mode
CNF
Config Mode
2
Operating
Command
K Keypad operation command
O FBus Option operation command
A Application Option operation command
R Built-in 485 operation command
T Terminal block operation command
3
Frequency
Command
K Keypad frequency command
V V1 input frequency command
I I1 input frequency command
P Pulse input frequency command
U
Frequency command during UP
operation (Up-Down operation)
D
Frequency command during DOWN
operation (Up-Down operation)
S
Frequency command during STOP
operation (Up-Down operation)
O FBus Option frequency command
X
V2, I2 frequency command of sub-
terminal block
J Jog frequency command
R Internal 485 frequency command
1~9 A~F Sequential frequency command
4
Multi
Function
Key
Setting
JOG Key Used for shift to Keypad JOG mode
Local/Remote
Used to select local or remote
operation
UserGrp
SelKey
Used to register parameters as a user
group in the parameter mode or delete
parameters in the user group.
5 Inverter STP Motor stopped
