LSIS SV-iS7 series User Manual

Chapter 9 Peripheral Devices
9-7
6) DB Resistors
(1) Option type Dynamic Breaking Unit
Following table has reference that DC breaking torque: 150%, %ED: 5%. Rating Watt of DBU has to be doubled
when %ED is 10%.
Vol
tag
e
Applied
inverter
capacity
(kW)
Format
150% braking torque, 5%ED
Resistance
[ohm]
Watt
[W]
Appearanc
e
2
0
0
V
Ἵ
0.75 BR0400W150J 150 150 TYPE 1
1.5 BR0400W060J 60 300 TYPE 1
2.2 BR0400W050J 50 400 TYPE 1
3.7 BR0600W033J 33 600 TYPE 2
5.5 BR0800W020J 20 800 TYPE 3
7.5 BR1200W015J 15 1200 TYPE 3
11 BR2400W010J 10 2400 TYPE 3
15 BR2400W008J 8 2400 TYPE 3
18.5 BR3600W005J 5 3600 TYPE 3
22 BR3600W005J 5 3600 TYPE 3
30 - 5 5000 -
37 - 4.5 7000 -
45 - 3.5 10000 -
55 - 3.0 15000 -
75 - 2.5 20000 -
4
0
0
V
Ἵ
0.75 BR0400W600J 600 150 TYPE 1
1.5 BR0400W300J 300 300 TYPE 1
2.2 BR0400W200J 200 400 TYPE 1
3.7 BR0600W130J 130 600 TYPE 2
5.5 BR1000W085J 85 1000 TYPE 3
7.5 BR1200W060J 60 1200 TYPE 3
11 BR2000W040J 40 2000 TYPE 3
15 BR2400W030J 30 2400 TYPE 3
18.5 BR3600W020J 20 3600 TYPE 3
22 BR3600W020J 20 3600 TYPE 3
30 - 12 5000 -
37 - 12 5000 -
45 - 6 10,000 -
55 - 6 10,000 -
75 - 6 10,000 -
90 - 4.5 15,000 -
110 - 3.5 17,000 -
132 - 3,0 20,000 -
160 - 2.5 25,000 -
185 - 2 30,000 -
220 - 2 30,000 -
280 - 1.5 40,000 -
315 - 1 60,000 -
375 - 1 60,000 -
Note
In case of iS7 90~160kW, rated resistor can use as braking unit when you use the 220kW
(SV2200DB-4). Or when used in conjunction with a parallel operable DB unit (SV075DBH-4), in
parallel a resistor and resistor values in the table above.
