LSIS SV-iS7 series User Manual

Chapter 2 SpecificationsG
G
2-2
2.1.3 Rated Input and Output : Input voltage of 400V class (0.75~22kW)
Type : SV xxx iS7 – 4x 0008 0015 0022 0037 0055 0075 0110 0150 0185 0220
1)
Motor Applied
[HP] 1 2 3 5 7.5 10 15 20 25 30
[kW] 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Rated Output
2
)
Rated Capacity
[kVA]
1.9 3.0 4.5 6.1 9.1 12.2 18.3 22.9 29.7 34.3
3)
Rated
Current[A]
CT 2.5 4 6 8 12 16 24 30 39 45
VT 4 6 8 12 16 24 30 39 45 61
Output Frequency
4
)
0 ~ 400 [Hz]
(Sensorless-1:0~300Hz, Sensorless-2,Vector:0~120Hz)
Output Voltage [V]
5)
3-phase 380 ~ 480V
Rated Input
Available Voltage [V] 3-phase 380 ~ 480 VAC (-15%~+10%)
Input Frequency 50 ~ 60 [Hz] (r5%)
Rated
Current [A]
CT 2.2 3.6 5.5 7.5 11.0 14.4 22.0 26.6 35.6 41.6
VT 3.7 5.7 7.7 11.1 14.7 21.9 26.4 35.5 41.1 55.7
* Non DCR products are provided warranty service when used in CT (Heavy duty) load
rating only.
2.1.4 Rated Input and Output : Input voltage of 400V class (30~160kW)
Type : SV xxx iS7
–
4x 0300 0370 0450 0550 0750 0900 1100 1320 1600 -
1)
Motor Applied
[HP] 40 50 60 75 100 120 150 180 225 -
[kW] 30 37 45 55 75 90 110 132 160 -
Rated Output
2)
Rated Capacity [kVA] 46 57 69 84 116 139 170 201 248 -
3)
Rated
Current[A]
CT 61 75 91 110 152 183 223 264 325 -
VT 75 91 110 152 183 223 264 325 370 -
Output Frequency
4)
0 ~ 400 [Hz]
(Sensorless-1:0~300Hz, Sensorless-2,Vector:0~120Hz)
Output Voltage [V]
5)
3-phase 380 ~ 480V
Rated Input
Available Voltage [V] 3-phase 380 ~ 480 VAC (-15%, +10%)
Input Frequency 50 ~ 60 [Hz] (r5%)
Rated
Current[A]
CT 55.5 67.9 82.4 102.6 143.4 174.7 213.5 255.6 316.3 -
VT 67.5 81.7 101.8 143.6 173.4 212.9 254.2 315.3 359.3 -
* Non DCR products are provided warranty service when used in CT(Heavy duty) load
rating only.
