LSIS SV-iS7 series User Manual

Chapter 2 SpecificationsG
2-1
2.1 Specifications
2.1.1 Rated Input and Output : Input voltage of 200V class (0.75~22kW)
Type : SV xxx iS7 – 2x 0008 0015 0022 0037 0055 0075 0110 0150 0185 0220
1)
Motor
Applied
[HP] 1 2 3 5 7.5 10 15 20 25 30
[kW] 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Rated Output
2
)
Rated Capacity
[kVA]
1.9 3.0 4.5 6.1 9.1 12.2 17.5 22.9 28.2 33.5
3)
Rated
Current[A]
CT 5 8 12 16 24 32 46 60 74 88
VT 8 12 16 24 32 46 60 74 88 124
Output Frequency
4)
0 ~ 400 [Hz]
(Sensorless-1: 0~300Hz, Sensorless-2,Vector: 0~120Hz)
Output Voltage [V]
5)
3-phase 200 ~ 230V
Rated Input
Available Voltage [V] 3-phase 200 ~ 230 VAC (-15%,+10%,)
Input Frequency 50 ~ 60 [Hz] (r5%)
Rated
Current [A]
CT 4.3 6.9 11.2 14.9 22.1 28.6 44.3 55.9 70.8 85.3
VT 6.8 10.6 14.9 21.3 28.6 41.2 54.7 69.7 82.9 116.1
* Non DCR products are provided warranty service when used in CT (Heavy duty) load
rating only.
2.1.2 Rated Input and Output : Input voltage of 200V class
ۡ
(30~75kW)
ۡ
Type : SV xxx iS7 – 2x 0300 0370 0450 0550 0750 - - - - -
1)
Motor Applied
[HP] 40 50 60 75 100 - - - - -
[kW] 30 37 45 55 75 - - - - -
Rated Output
2)
Rated Capacity
[kVA]
46 57 69 84 116 - - - - -
3)
Rated
Current[A]
CT 116 146 180 220 288 - - - - -
VT 146 180 220 288 345 - - - - -
Output Frequency
4)
0 ~ 400 [Hz]
(Sensorless-1: 0~300Hz, Sensorless-2,Vector:0~120Hz)
Output Voltage [V]
5)
3-phase 200 ~ 230V
Rated Input
Available Voltage [V] 3-phase 200 ~ 230 VAC (-15%~+10%)
Input Frequency 50 ~ 60 [Hz] (r5%)
Rated
Current [A]
CT 121 154 191 233 305 - - - - -
VT 152 190 231 302 362 - - - - -
* Non DCR products are provided warranty service when used in CT (Heavy duty) load
rating only.
